VISION Auto Security Systems Car Graphic
Add a sparkling array of light to your vehicle, with or without a security system
LM800 Series Scanning LEDs

LUMINATORLuminator Flash-n-Scan LEDs are a compact and affordable way to add a dazzling light show on your dashboard, while warning away potential thieves. Flashing patterns are user-selectable, and built-in flash memory retains your selection even if the power is cut. The LM800 also uses the latest LED technology to produce an ultra bright light without excessive drain on your car battery.
NEW!
price

Flash-n-Scan LEDs

LM800B

(BLU) JAN: 4571114021732

RETAIL PRICE: ¥6,300  (Before Tax: ¥6,000)

LM800W

(WHT) JAN: 4571114021749

RETAIL PRICE: ¥6,300  (Before Tax: ¥6,000)

LM800R

(RED) JAN: 4571114021725

RETAIL PRICE: ¥5,250  (Before Tax: ¥5,000)
Wiring Diagram

EASY 3-WIRE INSTALLATION
item4

Connect to battery Negative (or car body).

Connect to your alarm's ground-when-armed output or to your vehicle's ignition (if no alarm).

Specifications

Flashing Patterns:

16 (plus 3 speeds)

Dimensions:

38x51x13mm

Input Voltage:

12vdc

Avg. Current Usage:

10mA (LM800R: 15mA)

Mount:

2-sided tape

Connect to battery Positive (continuous +12v).

• LUMINATOR products are compatible with all VISION security systems.
• Connects to any alarm's GWA output: lights up when alarm is armed.

Made with Freeway
